This is post number 2 in the series about how we configured, built and tested our leaping arches.

Here we will discuss how to finalize the configuration of the AlphaPix controller.  You will need to make sure the controller is configured and powered on.  You will need to use a web browser from a computer on the same network as the controller.

  • In the web browser type in the IP of the controller and press enter
  • On the login screen, type the default password of 12345 and press enter
  • The configuration page will be displayed
  • Scroll down to the section titled SPI Pixel Output Configuration
  • Specify the
    • DMX Start Universe
    • Start Channel
    • Pixels connected
    • Null Pixels (if needed)
    • Reverse Addressing (if needed)
    • Intensity Limit (if needed)
  • Press the set button

The controller will apply your new setting.

Click Here for the Previous Post, Set the AlphaPix IP

Click Here for the next post, build and test the arches
